Einstein TC-02Mini 80 Column Adapter

‍

A simple, non-replica (schematics the same) remake of the TC-02 80 column board. Could be mounted on a ribbon cable, or as pictured on PC104 pin sockets (at full stretch). Required Character ROM at I4 in CHARROM folder. Please see the original manual for instructions for use.

‍

‍

Created by Ian Cudlip @grandoldian

Einstein-TC-01/Expansions/TC02Mini at main · Board-Folk/Einstein-TC-01

Its now time to start building as the Gerber file can now be downloaded from this page

‍
